3-15Table Of Contents www.SkeeterBoats.com
DEEP-V BOATS
Fuses and Relays Panel - WX1850 and WX1900
The fuse and relay panel is located under the helm console and behind the gauge and switch panel.
Replace a blown fuse with an identical replacement.
WARNING
Never use a replacement fuse of a different color, size, or amperage rating. An improper
fuse can cause damage to the electrical system which could lead to a re.
Fuse Relay Panel
Figure 3-13
