SKF LMC 301 series Installation Guide

Quick Setup/Installation Guide for Lubrication Monitor Controller LMC 301
951-150-029-EN
5
Display and control elements of control screen
Symbol Designation Function
Display
o Menu display / Display of values and parameters / Fault notification
o The right bar (
) indicates that the menu extends beyond the current display
PUMP
PUMP
Pumps A B C
Pump / Main line A / B / C per pump
max. 3 main lines supported
RUN
RUNning
Active control
LED lights up =
Indication of currently active pump/control line (A/B/C)
LL
Low Level
minimum fill level reached
LED lights up =
minimum fill level (pump A / B / C) reached
FAU LT
FAU LT
Error notification
o LED flashes = error detected
o LED lights up = fault
POWER
POWER Control unit on/off
LED lights up = Control unit on
Function keys
Control key in combination with the display above the key
"Up" arrow key menu control <Back menu level> / increase input value
"Down" arrow key menu control <Forward menu level> / reduce input value
Pressing triggers an interim lubrication.
By briefly pressing follows the choice of an additional lubrication.
Actuations while in configuration mode are ignored.
RESET
Long pressing (> 3 seconds) stops all systems or resets an error message.
Long pressing acknowledges and clears error messages.
RESET
P U M P A B C
RUN
LL
FA U LT
POWER
RESET
LMC 301
Display elements of control screen
Symbol Status Function
Stopped/
OFF o The system was stopped by pressing the Reset key and can be restarted by briefly pressing the Running key.
Pause o The respective lubrication area is currently in the interval time.
Wait Temperature o Temperature waiting time
Wait o Lubrication zone waiting because another zone currently being lubricated
Lubricate o The system lubricates
Hold o Holding time
Pressure relief o System relieved
Runtime o Pump runs
Secured/
Access denied
o No access as local admin or supervisor
Access o Access as local admin or supervisor
Fault o There is a fault.
Digital inputs/out-
puts on
o Digital output switched on
Digital inputs/out-
puts off
o Digital output switched off
