Quick Setup/Installation Guide for Lubrication Monitor Controller LMC 301
951-150-029-EN
7
3. Technical data
3.1 General technical data
Characteristics, design
General
Mounting position Vertical, refer to graphic, see page 14
Dimensions (L x W x H) 10.6299 x 6.6929 x 3.5433 in
Display 2.3622x1.1811 in 128x64 pixels
Environmental conditions
Altitude, up to AC 2000m / DC 5000m
Ambient/Operating temperature AC 14 to + 122 °F
Ambient/Operating temperature DC- - 40 to + 158 °F
Maximum relative humidity 80 % for temperatures up to
31 °C decreasing linearly to
50 % relative humidity at 40 °C
The LCD display only operates
down to -4°F
Storage temperature - 40 to + 158 °F
Application
≤ 150 VAC, indoor/outddor applications
3
),
UL overvoltage category III, pollution degree 2
> 150 ≤ 240 VAC only for indoor applications,
UL overvoltage category II, pollution degree 2
Connectivity via terminal block
Inputs: 10 count, short-circuit-proof, 2 are analog capable
Outputs: 8 count, relay outputs NO-contact 8A
of 2 to max. 15A
Residual ripple relative
operating voltage ±5% acc. to DIN 417 55
Protection and monitoring
Current limit Sustained short-circuit-proof
Overload-proof/ Open-circuit-proof Yes
Protection class
1
)
4
)
IP 65, protection class only with appropiate
cable glands PG-M20, without UL certification
Characteristics, design
Electronic consuming
Iternal fuse (LMC-Controller) 3 A
Input AC
Input voltage 100-240 VAC (50/60Hz)
customer Fusing (slow). 4 A (100-240 VAC)
Input DC
2
)
3
)
Input voltage 24 V DC ±10%
custermer Fusing (slow) 10 A
Output rating relays
Connection directly to the relay 01/02 100-240 VAC/ max. 15A
Connection directly to the relay 01/02 24 VDC/ max. 15A
Output terminal block 01 bis 08 24 VDC; 100-240 VAC/max. 8A
Note:
Do not mix 2 different voltages together (AC and DC) on
one terminal block!
Safety per DIN EN 60204-1
Safety class Class I
Customer connection cables
Temperature resistance of >158 °F
EMC
Interference suppression VDE 0875 T 11, EN 55011 Class A
Emitted interference acc. to EN 61000-6-3
Immunity acc. to EN 61000-6-2
Note
The emitted interference meets the requirements for industrial
use; use in a residential area may cause interference under some
circumstances.
LMC 301 Version Order No.
24 VDC 086500
100 to 240 VAC 086501
24 VDC I/O 086502
100 to 240 VAC I/O 086503
1) strain relief kid/cable glands -see
Operating instructions.
2) Applicable precautions for proper operation: “ Protective Extra Low
Voltage“ (PELV) and “Safe Extra Low Voltage“ (SELV).
3) The application as Outdoor (outdoor installation) has not been tested
in connection / certification with the UL standard
4) The degree of protection class for the controller LMC301 has not
been tested in connection with the UL certification
