Unit Configuration
Network Configuration
SKF Multilog On-Line System IMx-S 3 - 9
User Manual – Revision S
Table 3-10: TP/IP address/Unit ID when configured by HEX rotary switches.
TCP/IP
address/Unit ID
HEX1 (x10)
HEX2 (x1)
Software defined
01
02

99
0
0
0

9
0
1
2

9
Factory default configuration TCP/IP address:
10.0.0.1XY
Configurator (RS232) Interface
The RS232 interface is only used to set the neccessary network configuration
parameters.
The RS232 connector is located on the right-hand side of the IMx-S front panel, labelled
as COM.
Use a suitable USB to RS232 converter or serial null modem cable with a 9-pin, female,
D-SUB connector to connect to the IMx-S.
It is recommended to use a short length cable for the RS232 interface in order to
maintain full communication speed.
Important – the RS232 connector is to be used only whilst the necessary basic
network configuration setup is being done. The cable should not be connected to, or
left connected to, the RS232 connector at any other time.
Table 3-11: RS232 connector pinout.
RS232 Connector Pinout
Pin
Description
1
N.C.
2
Rx
3
Tx
4
N.C.
5
GND
6
N.C.
7
N.C.
8
N.C.
9
N.C.
N.C. = Not Connected
