Analogue Inputs
6 - 2 SKF Multilog On-Line System IMx-S
User Manual – Revision S
Analogue Inputs
• Analogue differential inputs:
– IMx-S 16: 16
– IMx-S 32: 32
• Individual 24 V power supply, maximum 35 mA per channel
• Selectable standard accelerometer power supply (4 mA constant current)
• Input range: ±25 V
• Impedance: >100 kΩ
Digital Inputs
• Digital opto-isolated inputs:
– IMx-S 16: 8
– IMx-S 32: 16
• Individual 24 V power supply, maximum 30 mA per channel:
– IMx-S 16: 4 channels
– IMx-S 32: 8 channels
• Trigger level: 2,9 V
– For inputs used with a signal level of 12 to 24 V note that the pulse should be
≥ 12 V.
Outputs
• Relay driver outputs:
– IMx-S 16: 4
– IMx-S 32: 8
• System relay outputs:
– IMx-S 16: 1
– IMx-S 32: 2
Analogue Measurement
• 24-bit AD conversion enabling continuous transient capture (no gain or AC/DC
switching necessary)
• True simultaneous sampling, with no multiplexing:
– IMx-S 16: all 16 channels
– IMx-S 32: all 32 channels
