Introduction
System LED Indicators
1 - 4 SKF Multilog On-Line System IMx-S
User Manual – Revision S
If less lines are used, the number of spectra is increased.
– When the buffer gets full, the oldest data is thrown away.
IMx-S 32
An IMx-S 32 is essentially composed of two IMx-S 16s.
• Up to 32 analogue channels.
• Up to 16 digital sensors with 8 configurable digital input channels for all standard
trigger sensors and 8 channels for square pulses with trigger level 12 to 24 V.
• IMx-S 32 unit has two CPU cards. Each CPU card separately has 4 MB flash memory
with the same storage capacity of IMx-S 16.
IMx-S features
• Individual conditions for alert and danger may be set for each measurement point.
• Each channel has indicators for alert and danger. Alert and danger levels may be
controlled by machine speed or load. However, it is also possible to manually bypass
the alert and danger functionality.
• The unit's built-in hardware auto-diagnosis system continuously checks all sensors,
cabling and electronics for any faults, signal interruption, short circuits or power
failure.
Initiating an IMx-S
Initiating the IMx-S is straightforward.
• It uses an initiating program @ptitude On-line Device Configurator or Multilog IMx
Configurator tool and a laptop computer using an RS232 serial interface.
• The network configuration parameters, such as IP address, IMx identification
number, etc. are first stored in a separate configuration file, then transferred to the
IMx-S memory. These are retained in the event of power loss, so that the IMx-S can
start automatically when power returns.
System LED Indicators
An IMx-S has two system LEDs on the CPU card.
• Red SYS LED indicates system fault. On means that a system fault has been
detected.
➢ Note that SYS LED is on for a short time when the system is cold
booted or re-started.
• Green PWR LED indicates the status of power. On means that the power is Ok.
