Unit Configuration
IMx-S Time
3 - 10 SKF Multilog On-Line System IMx-S
User Manual – Revision S
Figure 3 - 8.
Null Modem Cable Wiring.
IMx-S Time
IMx-S has a backup power capacitor which will keep the time for at least a month if IMx-
S is disconnected from a power inlet.
To correct or set IMx-S time, use one of the following methods.
• Automatic time synchronization
This method is preferable since the IMx-S will continuously synchronize the
time with the computer that has @ptitude Observer Monitor or Analyst IMx
Service running.
The IMx-S uses a built-in function (NTP) in Windows for time synchronization.
In order to activate time synchronization, refer to Time Synchronization chapter
in "@ptitude Observer Installation Manual".
• Manual set time
Use "Set time" function in @ptitude Observer or @ptitude Analyst application.
In @ptitude Observer, the function is found under a tab menu called "On-line",
then "MasCon/IMx units" interface.
In @ptitude Analyst, the function is found at Transfer / Online / Status.
