7SKF TKRT 10
Optical measurement
Rotational speed range 3 to 99 999 r/min
Accuracy ±0,05% of reading ±1 digit
Measuring distance 50 to 500 mm (1.9 to 19.7 in)
Angle of operation ±45°
Laser sensor 1 × built-in class 2 laser
Contact measurement
Rotational speed range 2 to 20 000 r/min
Accuracy ±1% of reading ±1 digit
Contact adaptors Included with conical tip,
conical recess and wheel
Battery and power
Battery 1 × 9 V alkaline type IEC 6F22
Operation time 12 hours continuous use
Additional power source 6 V DC charging port
(charger not included)
Size and weight
Product dimensions 160 × 60 × 42 mm
(6.3 × 2.4 × 1.7 in)
Product weight 160 g (0.35 lbs)
Carrying Case
dimensions
260 × 85 × 180 mm
(10.3 × 3.4 × 7.0 in)
Total weight
(incl. case)
680 g
(1.5 lbs)
Operating requirements
Operating temperature 0 to 50 °C (32 to 122 °F)
Storage temperature –10 to +50 °C (14 to 122 °F)
Relative humidity 10 to 90% RH non-condensing
IP rating IP 40
