If correct tension is unattainable, contact an authorized SKI-DOO
dealer.
A31F0IA
2
3
1
1. Adjustment screw
2. Loosen lock nut
3. Loosen screw
Alignment
NOTE:
Track tension and alignment are interrelated. Do not adjust
one without the other.
WARNING
Before checking track alignment, ensure that the track is free of
all particles which could be thrown out while track is rotating.
Keep hands, tools, feet and clothing clear of track. Ensure no
one is standing in close proximity to the snowmobile. Never
rotate track at high speed.
Start the engine and accelerate slightly so that track barely rotates.
The track should be rotated less than 20 seconds to prevent track's
shrink, due to the heat during working. Check that the track is well
centered; equal distance on both sides between edges of track
guides and slider shoes.
82
