Cross-line laser 0511
INTRODUCTION
• The measuring tool is intended for determining and checking horizontal and vertical
lines
• The measuring tool is suitable exclusively for operation in enclosed working sites
• This tool is not intended for professional use
• Save these instructions for future reference and include them with the
measuring tool when giving it to a third party
TECHNICAL DATA
Working range to approx. 10 m
Levelling accuracy ±0.5 mm/m
Self-levelling range ± 4°
Levelling time ≤6 seconds
Operating temperature +5°C to +40°C
Storage temperature -20°C to +70°C
Relative humidity (max.) 90%
Laser class 2
Laser type 650 nm, <1 mW
Tripod mount 1/4”
Batteries (included) 2 x AA (LR6) 1.5V
Operating life time (approx.) ≥15 hours
Weight 0,3 kg
Dimensions (length x width x height) 75 x 63 x 83.5 mm
TOOL ELEMENTS 1
A Battery lid
B Latch of battery lid
C On/O button / Mode button
D Exit opening for laser beam
E Automatic levelling indicator
F Switch for automatic levelling / locking the levelling unit
G Holder
H Fastening screw of holder
J Tripod mount 1/4”
K 1/4” screw of holder
L Locking screw for holder
M Laser viewing glasses*
N Tripod*
* NOT STANDARD INCLUDED
SAFETY
• All instructions must be read and observed in order to work safely with the
measuring tool 2
• Never make warning signs on the measuring tool unrecognisable
•
The use of other operating or adjusting equipment or the application of
other processing methods than those mentioned here can lead to
dangerous radiation exposure
