-7-
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Reciprocating Saw
NOTE: For tool specifications refer to the nameplate on your tool.
ADJUSTABLE
FOOTPLATE
RUBBER
BOOT
TRIGGER "ON-OFF" SWITCH
SAWBLADE
VARIABLE
SPEED DIAL
FIG. 1
RUBBERIZED GRIP
(Model 9216 only)
POWER INDICATOR LIGHT
(Model 9216 only)
VENTILATION
OPENINGS
BLADE CLAMP
RELEASE LEVER
HEX WRENCH AND STORAGE
COMPARTMENT
