Fig. 10 - parameters table
number
factory
values of values of
of parameter
values
application application
11 Amplitude 34,00%
12 Timeout ON 00.0s
13 Timeout OFF 00.0s
14 Starting time 01.0s
15 Batch ON 00.0s
16 Batch OFF 00.0s
17 Ampl. MAX 100%
18 Ampl. MIN 20%
19 Input IN1 not connect.
20 Sensor 1 type NO
21 Input IN2 not connect.
22 Sensor 2 type NO
23 Analogue AIN not connect.
24 Output OUT1 not connect.
25 Timer T11 00.0s
26 Timer T12 00.0s
27 Timer T13 000s
28 Output OUT2 not connect.
29 Timer T21 00.0s
30 Timer T22 00.0s
31 Timer T23 000s
34 Frequency 50Hz
36 Activation by button
37 Service fnc not used
38 Password 0
39 Locking
40 Language english
41 Info info
