4. The unit is now ready to test. Turn on the appropriate power switch(es) pt 5.
Press a button on the front panel. The unit will start and the display (with no
data) will be displayed.
Note: The factory default has brightness low and night picture and may need adjusting
to be seen in bright sunlight.
Mounting the Transceiver.
LED A
Power
1. Mount the unit on a solid wall. (The
unit weighs 17 kg). Ground the unit via
the bolts or with a cable to the ships
ground. Route power to the unit
(mains/24DC or both, The unit needs at
least 60W at peak.)
2. Turning on the power with no cabling
will not damage the unit, LED A
should light.
(8-10mm bolts are needed to mount the unit to
the wall, not supplied)
Installing the Gate valve (See separate manuals for full
details) SB-100-Manual and DB-100-Manual.
