6.9 Disassembling and assembling cou‐
pling
⇒ “6.9.1 Replacing generation II four-wheel drive clutch grooved
ball bearing, final drive 02D, 0AV, Octavia II”, page 128
6.9.1 Replacing generation II four-wheel drive
clutch grooved ball bearing, final drive
02D, 0AV, Octavia II
Special tools and workshop equipment required
♦ Counterholder - T10172-
♦ Adapter - T10172/5-
♦ Engine and gearbox jack - V.A.G 1383 A-
♦ Tensioning strap - T10038-
♦ Rig tool - T30004 (3415)-
♦ Three-arm extractor e. g. -VAS 251 201- or -Kukko 12-1-
♦ Ejection lever - MP3-418 (VW 681)-
♦ Two-arm extractor e. g. -VAS 251 001- or -Kukko 20-10-
♦ Pressure plate - MP3-407 (VW 402)-
♦ Pressure spindle - MP3-408 (VW 412)-
♦ Pipe - T30034 (41 - 501)-
♦ Pressure spindle - T30055 (3296)-
♦ Assembly tool - T10030-
♦ Pressure spindle - T10019-
♦ Pipe - MP3-409 (VW 418 A)-
♦ Thrust piece - MP3-411 (VW 454)-
♦ Thrust piece - MP3-453 (VW 431)-
♦
♦ Locking agent - D 000 600-
♦ Catch pan
♦ Allan screw M8 x 15
♦ Screw M10 x 25
Removing
– Raise vehicle.
NOTICE
Risk of damage to the decoupling element of the exhaust sys‐
tem.
The decoupling element must not be bent or kinked by more
than 10°.
– Do not load the decoupling element with tensile stress.
– Do not bend the decoupling element excessively.
Octavia II 2004 ➤ , Octavia II 2010 ➤ , Superb II 2008 ➤ , Superb II 20 ...
Propshaft and rear final drive - Edition 10.2018
128 Rep. gr.39 - Final drive - rear differential
