– Press on cardan shaft flange.
– Then screw in new nut using locking agent - D 000 600- and
tighten.
A - Screw M10 x 25
B - Allen screw M8 x 15 (is screwed in from the reverse side into
the counterholder - T30004- )
C - Counterholder - T30004-
– Install four-wheel drive clutch
⇒ “6.8.1 Removing and installing generation II four-wheel drive
clutch, final drive 02D, 0AV, Octavia II”, page 115 .
– Install propshaft at rear final drive
⇒ “1.3 Removing and installing propshaft”, page 26 .
– Install exhaust system and align free of stress ⇒ Engine; Rep.
gr. 26 .
– Check the oil level in the four-wheel drive clutch, top up with
oil if necessary
⇒ “6.4 Checking oil level in the four-wheel drive clutch”,
page 106 .
6.10 Removing and installing control unit
⇒ “6.10.1 Removing and installing generation II four-wheel drive
clutch control unit, final drive 02D, 0AV, Octavia II”, page 134
⇒ “6.10.2 Removing and installing generation IV four-wheel drive
clutch control unit, final drive 0BR, Octavia II, Superb II, Yeti, up
to 10/2013”, page 137
⇒ “6.10.3 Removing and installing V generation four-wheel drive
clutch control unit, Yeti, from 11/2013”, page 139
6.10.1 Removing and installing generation II
four-wheel drive clutch control unit, final
drive 02D, 0AV, Octavia II
Special tools and workshop equipment required
♦ Catch pan
Octavia II 2004 ➤ , Octavia II 2010 ➤ , Superb II 2008 ➤ , Superb II 20 ...
Propshaft and rear final drive - Edition 10.2018
134 Rep. gr.39 - Final drive - rear differential
