This instruction manual is applicable to 3 models. Take a moment to nd the model of your
telescope. Follow the instructions for your specic model in the manual. Read the entire
instructions carefully before beginning. Your telescope should be assembled during daylight
hours. Choose a large, open area to work to allow room for all parts to be unpacked.
1.1 Finderscope/Red dot nder assembly
1. Attaching the nderscope bracket(Fig.1.1.1a)
• Locate the nderscope optical assembly.
• Slide the nderscope bracket into the rectangular slot and tighten the screw to hold the
mount in place.
refractor Maksutov
Fig.1.1.1a
2. Attaching the red dot nder(Fig.1.1.2a)
• Slide the red dot nder bracket into the rectangular and tighten the screw to hold the red
dot nder in place.
Fig.1.1.2a
