Skydroid MX450 - Drone Ba Ery; Smart Ba Ery Function

2
1.2 Drone baery
1.2.1 Drone baery charging
2 axis gimbal
SD card slot
Pairing key
Pairing indicator
Propeller
Megaphone
RGB status light
GPS
Brushless motor
Baery
Power supply port
Balance charging port
Thrower
Searching light
Assistant port (Micro-USB
Laser obstacle avoidance (optional)
No. Annotation AnnotationNo.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1.3 Smart baery functions
Automatic discharge protection for baery storage: After being fully charged and
left without any operation for 2 days, the baery will discharge to 11.5V (a slight
heat during this period is a normal phenomenon) to protect the baery.
The drone uses a 3S smart lithium baery with a capacity of 4200mAh and a
nominal voltage of 11.1V. Standard equipped with a smart charger. The charging
time is about 1.5 hours.
①Insert the baery charging plug into the connector.
②Connect the power adapter to the AC power supply.
③The current voltage will be displayed in the charger.
④Please make sure to charge the baery at an ambient temperature between
0-40°C.
⑤The charger displays FUL and 13.0V alternately, which means the baery is fully
charged.
电池充电插头
电压显示界面
220V交流电源
Baery charging plug
Voltage display interface
220v AC power supply
