SJIII Compacts & Conventionals
December 2007 Page 45
Section 2 - Operation Loading/Unloading
NOTE
The mass of the aerial platform is as per
Table 2.3a or Table 2.3b. The center of
gravity is approximately located in the
middle of the aerial platform, front to
back and side to side, as illustrated in
Figure 2-19. Vertically, the center of gravity
is approximately just above the base
chassis.
NOTE
The aerial platform can be lifted with a
forklift from the sides but Skyjack does
not recommend this use. Lift with forks
in designated pockets as illustrated in
Figure 2-20.
2.12-2 Driving
Before driving the aerial platform:
Ramp or dock capacity must be sufficient to •
withstand maximum aerial platform weight.
Ramp should be equipped with side guards to •
prevent inadvertent fall from the ramp.
Incline should not exceed aerial platform •
gradeability (refer to Table 2.3a or Table 2.3b).
Aerial platform brake must be checked for proper •
operation.
Aerial platform speed should be on high torque •
setting (if equipped).
WARNING
When transporting, the aerial platform
must be secured to the truck or trailer
deck. Tie downs are available as illustrated
in Figure 2-18.
Forklift pocket Forklift pocket
Rear of aerial platform
Figure 2-20. Forklift Pockets
