Page 28 December 2007
SJRT Compact Series
Engine Powered
Function Tests Section 2 - Familiarization
It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
• Test Free-wheeling
1. Ensure path of intended motion is clear.
2. Release the brake manually (refer to
Section 2.5-2).
3. Turn free-wheeling valve knob counterclockwise
to a fully opened position and attempt to push/
pull the aerial platform.
Result: Aerial platform should move.
4. Turn free-wheeling valve knob clockwise to a
fully closed position for normal operation.
5. Reengage the brake (refer to Section 2.5-2).
FAMILIARIZATIONFAMILIARIZATION
Brake Hand
Pump
Free-wheeling
Valve
Brake Auto
Reset Valve
Emergency
Lowering
Valve
Emergency Main Power
Disconnect Switch
Emergency Stop
Button
Platform/Engine/Base
Key Switch
Base Control Console
Main Manifold
To Next Page
