lb. kg lb. kg psi kPa psf
kg/m
2
min* 6400 2903 2560 1161 152 1046 206 1007
max* 8666 3931 3466 1572 168 1159 280 1364
min*
7286
3305 2914 1322 37 256 235 1146
max*
8666
3931 3466 1572 44 305 280 1364
min* 7661 3475 3064 1390 162 1114 247 1205
max* 9189 4168 3675 1667 171 1179 296 1446
min* 8058 3655 3223 1462 41 283 260 1268
max* 9189 4168 3675 1667 47 323 296 1446
1014AA-ANSI
*
**
NOTE:
6832
min - Total aerial platform weight with no options
max - aerial platform weight + all options + full capacity
The LCP or OUP that an individual surface can withstand varies from structure to structure and is generally determined by the
engineer or architect for that particular structure.
OUP – Overall Uniform Pressure is a measure of the average load the aerial platform imparts on the whole surface directly
underneath it. The structure of the operating surface (beams, etc.) must be able to withstand more than the indicated values
MODEL
6832
Outrigger Pads
Total Aerial Platform Load
Total Aerial Platform
Weight
Wheel OUP**
6826
6826
Outrigger Pads
LCP**
LCP – Locally Concentrated Pressure is a measure of how hard the aerial platform presses on the areas in direct contact with
the floor. The floor covering (tile, carpet, etc.) must be able to withstand more than the indicated values above.
