238264AAA SJ45 AJ+, SJ60 AJ+
86
Section 7 – Technical Diagrams and Specifications Technical diagrams
Dimensions - SJ45 AJ+ (continued)
0.17 m
(
6-1/2 in)
0.64 m
(25 in)
1.11 m
(44 in)
DETAIL A
1.52 m
(60 in)
1.83 m
(72 in)
or
175º
75º
0.76 m
(30 in)
1.14 m
(45 in)
70º
1.42 m
(55-3/4 in)
2.7 m
(106-1/2 in)
0.61 m
(2 ft)
2.29 m
(7 ft 6 in)
1.5 m
(4ft 11-1/4 in)
4.34 m
(14 ft 3 in)
0.09 m
(3.7 in)
