Page 20 December 2007
Rough Terrain Scissors
TM
Visual & Maintenance Inspection Section 2 - Familiarization
It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATIONFAMILIARIZATION
• Main Manifold
- Ensure all fittings and hoses are properly
tightened and there is no evidence of
hydraulic leakage. Pull and tilt main
manifold to check thoroughly.
- Ensure there are no loose wires or
missing fasteners.
- Restore to original position.
• Gear Type Flow Divider
- Ensure there are no loose or missing
parts and there is no visible damage.
Hydraulic
Tank
Fuel Tank
Hydraulic Oil
Filter
Gear Type
Flow Divider
Main
Manifold
Oil Level
Gauge
Fuel Level
Gauge
To Next Page
