Rough Terrain Scissors
December 2007 Page 35
Section 2 - Familiarization Procedures
It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATIONFAMILIARIZATION
2.5-2 To Release the Brakes Manually
WARNING
Do not manually disengage brakes if the
MEWP is on a slope.
1
2
Figure 2-9. Disc Brakes System
NOTE
Brakes must be manually disengaged for
pushing, winching or towing.
1. Ensure MEWP is on level ground. Chock or block
wheels to prevent MEWP from rolling.
2. Turn main power disconnect switch to “ ” off
position.
3. Locate brake auto reset valve plunger (item 1) and
brake hand pump (item 2) at the main manifold in
the hydraulic/fuel compartment.
4. Push in brake auto reset valve plunger.
5. Grasp brake hand pump and rapidly depress
until firm resistance is felt. The brakes are now
released.
6. Remove wheel chocks or blocks, then push, winch
or tow MEWP to desired location.
WARNING
Brakes must be reengaged immediately
after reaching the desired location.
7. Position MEWP on a firm and level surface.
8. Chock or block wheels to prevent MEWP from
rolling.
9. Reengage brakes by pulling out brake auto reset
valve plunger.
