10. Technical Specication
DATA SERVICE PORT
Connector 9-pin D-sub female
Data protocol
RS232C interface. The DVB-DSR is seen as the Data Communication
Equipment (DCE) and the PC (or other terminal) is seen as the
DataTerminal Equipment (DTE).
Data rate Maximum of 625K bits/s
POWER SUPPLY
Main input voltage
2 3 0 VA C
Nominal power consumption 12W
SAFETY
Insulation resistance
More than 10MΩ @500VDC Ambient conditions of 28 ± 2% & 70% RH
Withstand Voltage (Hi-Pot) I/p to O/p: 3kV(1 min)
Temperature Rise < 75°C on winding & core < 50°C on casting At 264Vac @ 50Hz
Safety Standard Designed to meet IEC 9
MICROPROCESSOR
Microprocessor CONEXTANT
Clock frequency 130MHz
SDRAM Memory 8Mb
Flash memory 1Mb
PHYSICAL CHARACTERSTICS
Front panel
Keys 7 Keys
Indicators Power ON/OFF
Remote control input Infra-red receiver
Display 4Digital (7 Segment)
Rear panel
Connectors
1 LNB Input / 1 Loop through output (2F-type)
1 x Scart output , 1 x VCR Scart
1 x Digtal stereo audio coaxial
1 x RS-232 (9-pin D-sub male)
1 x RF in/TV aerial in
1 x RF out
Customer Careline: 0901 293 0038
Calls are charged at £1 per minute from a BT landline.
Call charges from other networks may vary
Technical Support: http://technical.philex.com
