SkyLine 28207RF User Manual

19
10. Technical Specication
10
TRANSMISSION STANDARDS
DVB, MPEG-2
INPUT/ DEMODULATION
Connector Type 2x F Type, 3/8-32UNEF-2A (1 input/1 loop through)
Input
Frequency 950 to 2150 MHz
Signal
Input level -65 to - 25 dBm
Band
Switch control 22 KHz
LNB
Supply 13.0V + 0.5V / 18V + 0.7V, max 400mA
Demodulation
Type QPSK / FEC Coding (DVB ETS 300 421)
Symbol
Rate 2 < Rs < 45 Mbaud (SCPC/MCPC)
TV SCART
Video output
CVBS/75Ω unbalanced
RGB
bandwidth 5MHz
Fast
blanking 0V to 3V
Function
switch
6V - 16:9 aspect ratio image (AV Mode)
12V - 4:3 aspect ratio image (AV Mode)
Audio
output
“Left, Right”/ 600Ω unbalanced
Level
1.0V rms ± 2dB into 10kΩ
VCR SCART
Video output
CVBS/75Ω unbalanced/5MHz
Video input
CVBS/75Ω unbalanced/5MHz
Audio output
“Left, Right”/ 600Ω unbalanced
Level
1.0V rms ± 2dB into 10kΩ
Audio input
“Left,
Right”/10kΩ unbalanced
Level
1.0V rms ± 2dB into 10kΩ
AUDIO/VIDEO PROCESSING
Audio Decompression MPEG-1 layer I and II / Musicam
Audio Outputs Stereo Digital Coaxial
Video Decompression MPEG-2 Main Prole @ Main Levels With Letter
Video buer 64 Mbits of SDRAM is provided
Data rate Up to 15Mbits/s (Max. burst rate: 228 Mbits/s)
Video output PAL-25 frame @720 x 576 NTSC-30 frame @720 x 480
Video format 4:3, 16:9
Technical Support: http://technical.philex.com
Customer Careline: 0901 293 0038
Calls are charged at £1 per minute from a BT landline.
Call charges from other networks may vary
Technical Support: http://technical.philex.com
