OPERATING PROGRAM
Here is the detailed procedure to make the charger work. All the screens and operations
will take Li-Po BALANCE CHARGE program for example,
Note: We will explain one channel as the operating procedure
of Channel A and Channel B is identical.
1. Connection
Connecting to power source
There are two kinds of inputs for SKYRC D200, DC 11-20V and AC 100-240V.
A. Operating in AC mode
SKYRC D200 comes with built in switching power supply. You can connect the AC
power cord directly to the main AC socket. (100-240V AC).
Note: The charging power in AC mode is 200W totally for Channel A and Channel B.
In AC mode, it supports Power Distribution. The total power for Channel A and
Channel B is 200W. You could set the AC Max Power for one channel (Take
Channel A for example)as following,
And the other channel (Channel B) will take the rest power automatically (For example, if
you set channel A as AC 150W, the channel B will be AC 50W).
If Channel A and Channel B are both charging, you can’t change the AC power.
If Channel A is charging, you can change AC power of Channel B and Channel
A will take the rest power automatically.
B. Operating in DC mode
Please connect SKYRC D200 with AC/DC power supply by supplied DC input cable. Also
you could use terminal clips with DC connectors, for attaching directly to 12V car
batteries. It is critically important that you use either a fully charged 13.8V car battery or a
high quality AC/DC power supply in the range of 11-20V DC output with minimum power
360W or higher to insure reliable performance.
Note: The charging power in DC mode is 200W for Channel A and 100W for Channel B.
Total power of D200 is 300W.
1).
BATT/PROGRAM
SYSTEM SETTING->
LIPO BALANCE
5.1A 22.2V(6S)
A
B
AC Max Power Set
150W
LIPO BALANCE
5.1A 22.2V(6S)
A
B
AC Max Power Set
150W
A
B
AC Max Power Set
50W
Safety Timer
ON 120Min
LIPO BALANCE
5.1A 22.2V(6S)
A
B
11 ·
D200
NOTE1:
NOTE2:
