Skytech RCT-MLT IV User Manual

Skytech: RCT-MLT-IV
REV. 3-26-19 Page 2
THERMOSTAT FUNCTION
SETTING THE CLOCK
• Hold the TIMER/TIME button for 3 seconds. The hour section of
the time should begin ashing.
• Select the hour by pressing the UP and DOWN buttons. If you
go past 12 o’clock the AM and PM will change.
• Once the hour is selected, press and release the TIMER/TIME
button again, and the minute section of the time should be
ashing.
• Use the UP and DOWN buttons to scroll through the minutes.
• Once the minutes are correct, press and hold the TIMER/TIME
button for 3 seconds. The time is now set.
SETTING THE COUNTDOWN TIMER
This remote control system can operate with a built-in countdown timer when the transmitter is in the ON or THERMO modes
(THERMO or ON must be displayed on the screen).
• Press and release the TIMER button. The minimum 0:15 minute setting on the will begin to ash.
• Press the UP or DOWN button on the transmitter to chose your countdown time. Available countdown times are
15 min, 30 min, 45 min, 1 hour to 9 hours (alternating every 30 min).
• To initiate the countdown, simply press the SET button or wait 15 seconds for it to stop ashing. The appliance
will turn off when the timer runs out.
• Press the MODE key until the LCD screen shows the word
“THERMO” at the top of the screen.
• To adjust set temperature, press the UP and DOWN
buttons until the desired temperature is reached. The
temperature range is 99ºF (32ºC) to 45ºF (6ºC).
• If no button is pressed, the set temperature will
automatically be accepted.
• The ame icon will appear when the control calls for heat.
The ame icon will disappear when the appliance reaches
its set temperature.
• Press the MODE key to disengage the Thermo Mode.
OPERATING THE FAN
This remote control system has the capability of operating a 110 VAC fan or blower system that may be included with you gas replace.
The fan will only operate when the transmitter in the ON or THERMO modes (THERMO or ON must be displayed on the LCD Screen).
• To turn on the fan, press the FAN button on your transmitter.
• You can switch through the various positions by pressing the fan until the desired speed is obtained.
• Your speed options are High, Medium, Low, and Off.
FLAME HEIGHT
This remote control system allows the user to control the height
of the ame when the gas valve is factory equipped with a ame
controller.
• Press and release the ame button to change the ame from
regular to HI.
• When the ame is switched to HI, the word HI in a black box and
a second ame appears in the lower right hand corner of the
LCD screen. When switched back to regular ame, they both
disappear.
RECEIVER
The remote receiver os powered by 110-120VAC. It plugs into a standard polarized duplex receptacle. The remote receiver has a
3-position slide switch for selecting the mode of operation ON/REMOTE/OFF
• ON: will manually turn on the appliance.
• REMOTE: will allow use of handheld transmitter. If the system does not respond to
the transmitter on initial use, check the battery positions in the remote. If that does not
work, see the LEARNING TRANSMITTER TO RECEIVER section.
• OFF: will disable the remote receiver.
O
F
F-
R
EMOT
E
-
O
N
G
R
OU
N
D
VA
L
V
E
L
E
AR
N
C
O
N
T
R
O
L
FL
A
M
E
SETTING THE TEMPERATURE SWING
(TEMPERATURE DIFFERENTIAL)
The Thermo Mode on the transmitter operates the appliance
whenever the room temperature varies a certain number of
degrees from the set temperature. This variation is called the
“SWING” or TEMPERATURE DIFFERENTIAL. The factory
preset swing temperature is 2 ºF (1 ºC). To change the “Swing
Setting:”
Note: This product is designed for use with an attended hearth appliance or re
feature. Adults must be present when the Control System is operating. DO NOT
program or thermostatically set this Control to operate a hearth appliance or re
feature when Adults are not physically present. Furthermore, DO NOT leave the
hearth appliance or re feature burning unattended; it may cause damage or
serious injury. If an Adult is going to be away from the hearth appliance or re
feature for any length of time, then the handheld/wall mount, receiver/control
module and application should be in the “OFF” position.
