Skytrac CDP-300 Series User Manual

CDP-300 Installation Manual
Document Rev. 01.006 DOC0449 Page 11 of 31
Restricted Proprietary and Confidential Information
1.3 SYSTEM COMPONENTS
The CDP-300 is a peripheral of the ISAT-200 System. The CDP-300 can operate stand alone or in conjunction
with a DVI-300 (CDP/DVI mode). The CDP/DVI must be connected to an ISAT-200 with up to date firmware
versions on all STS equipment. Refer to the CDP-300 User’s Guide (DOC0500) or www.skytrac.ca for the
firmware revisions needed for the CDP-300 and ISAT-200.
1.3.1 ISAT-200
The ISAT-200 is the primary component of the ISAT-200 System. The ISAT-200 provides position reporting and
messaging with global coverage in near real time. The CDP-300 provides a user cockpit control head to the
system. Please refer to the ISAT-200 installation manual for more information regarding installation of the ISAT-
200.
Figure 1 – ISAT-200 System Block Diagram
