Skytrac CDP-300 Series User Manual

CDP-300 Installation Manual
Document Rev. 01.006 DOC0449 Page 14 of 31
Restricted Proprietary and Confidential Information
2 SYSTEM SPECIFICATIONS
2.1 GENERAL
This section contains the specifications and a list of the physical and electrical requirements for the CDP-300.
2.2 POWER REQUIREMENTS FOR THE CDP-300 SYSTEM
Table 2 – Power Requirements
COMPONENT
POWER REQUIREMENTS
CDP-300
Input Voltage: 20.5 to 32 VDC, 28 VDC nominal
Average Power: 7 W typical, 12W maximum
2.3 DIGITAL AND ANALOGUE I/OS
Table 3 – Digital and Analogue I/Os
Current Sinking Output
Maximum: 32 VDC, 200 mA
RS-232 Ports
Meets requirements of TIA/EIA-232-F standard
TX maximum: +/- 13.2 V, RX maximum: +/- 25V
RS-485 Ports
Meets requirements of TIA/EIA−485−A standard
Fail-safe receiver: Open circuit
Refer to the CDP-300 User's Guide (DOC0500) for configuration options.
