PARTS LIST
Figure 1
Item Part No. Description
1 3198097 Cover Lens, Glass
- 1198062 RTV Silicone Sealant (3 oz. Tube)
2 3250024 Lamphead Housing, Fiberglass
3 3118035 Latch (2 req’d.)
- 3240463 Nut Plate, Latch (not shown)
4 3240462 Catch(mountstoItem32;2req’d.)
5 3198098 Lower Gasket, Trimlock
6 4151767 Shoulder Bolt, 5/16 x 3/4" 1/4-20 Thrd.
- 4317001 Flatwasher, 5/16"
7 3158005 Compression Spring, .720" x .75"
8 3158006 Compression Spring, .300" x 2.0”
9 4102000 Screw, 10-32 x 2" Socket Head
10 3250013 Bulb Support Spider
- 3161007 Thermal Switch
11 3250244 Positive Lead (2 req’d.)
12 3250177 Radiation Shield & Anode Clamp
13 3250435 Reector&RingAssembly,Parabolic
14 3250055 Blower, 220 V.AC, 50/60 Hz. (2 req’d. for 4 kW)
15 319813 Gasket, Blower Outlet
16 3240090 Cover Plate
17 3240088 Blower Box
18 3220031 Insulator Plate
19 3250032 Transformer (4 kW)
19 3250033 Transformer (2 kW)
20 3240084 Support Bracket, Right
21 3220030 Ring, Blower Coupling
22 3140083 Support Bracket, Left
23 39110000 Capacitor
24 3240089 Base Plate, Lower Bulb Support
25 3250036 RF Coil Assembly (2 kW)
25 3250053 RF Coil Assembly (4 kW)
26 8161018 Spark Gap
27 3198076 Mounting Bracket, Cathode Receiver (2 req’d.)
28 3220029 Spacer Block, Bracket (2 req’d.)
29 (ref.) Plate (welded to Item 32 Frame)
30 3198078 Cathode Receiver, Threaded
31 3198163 Strain Relief Bushing
32 3240098 Frame, Welded Assembly
33 3240084 Support Bracket, Right
