Item Part No. Description
1 3240550 Hinged Access Door
2 3172002 Toggle Switch
3 3240545 Instrument Panel Plate (less Components)
4 3270242 Printed Circuit Board Assembly (208/230 V.AC)
4 3270322 Printed Circuit Board Assembly (380/440 V.AC)
- 2121016 Fuse, 1 A. 250 V. (4 req’d.)
5 3240549 Operator’s Side Panel
6 85109000 Air Flow Switch
7 2240854 Switch Mounting Bracket
8 1102001 Blower, 230 V.AC, 50/60 Hz.
9 3240425 Cover Plate (as req’d.)
10 3200059 Mounting Flange
11 3240524 Floor Plate
12 3240528 Side Panel (2 req’d.)
13 3198121 Blower Intake Gasket (order 2 feet)
14 3220107 Blower Coupling Collar
15 --- XenonPowerSupply(seeFigure5;4req’d.)
16 3162044 Terminal Block
17 3240526 Base Leg, Welded Assembly (4 req’d.)
18 3200308 Base Frame, Welded Assembly
19 3240527 End Panel, Off-Operator’s Side
20 3198248 Master Link, Roller Chain
21 3198102 Roller Chain, (48) link length
22 3159001 Drive Sprocket, 10 Tooth
23 3220085 Driven Sprocket, 36 Tooth
24 3220139 Spacer (2 req’d.)
25 3104002 Pillow Block
26 3143001 Drive Pulley, Timing Belt
27 3105001 Timing Belt
28 3240596 Motor Mounting Bracket
29 3133024 Drive Motor (208/230 V.AC, 60 Hz.)
29 3133012 Drive Motor (380/440 V.AC, 50 Hz.)
30 3220084 Gearbox Assembly
31 3240338 Bracket & Stud Assembly
- 3220087 Stud Bushing (not shown)
32 3220126 Spacer
33 3104004 Ball Bearing (4 req’d.)
34 3198100 Top Cover
35 6139001 Name & Data Plate (as req’d.)
36 40191000 Ammeter
37 3132001 Elapsed Time Meter
PARTS LIST
Figure 3
