12
STEP 11
Place the frame pad (6) on top of the springs. Adjust the frame pad so that
the slits are directly above the T-sockets and the logo tag on the pad is to
the right of the enclosure door as shown.
Important: Don’t use the trampoline without the frame pad. It’s designed to
protect your little jumpers! Trust us on this one.
Frame Pad (x1)
6
Socket
Slit of Pad
(6)
ASSEMBLY
Enclosure door
LOGO Label
STEP 12
Look under the trampoline. Find the straps that are attached to the underside of the frame pad (6). Position
the inner straps so that one strap is threaded through one V-ring then clipped to the side of the V-ring next to
it as shown. Position the outer straps so they wrap under the frame and attach to a V-ring.
Inner strap
Underside of trampoline
threaded
through a
V-ring
clipped
to the
side
Underside of trampoline
outer hook
To Next Page
