9
T-joint
Warning label
Warning label
Enclosure door
T-joint
Enclosure door
First V-ring
First hole
T-joint
STEP 6
You may want to use gloves for this step! Before you begin, make sure
each V-ring has been threaded through the holes on the enclosure
net. Make sure the enclosure door is lined up with a T-joint. Using the
spring tool, hook the smaller end of a spring into the V-ring just left of
the enclosure door. Stretch the free end of the spring until it reaches
the frame hole just left of the T-joint.
Springs (x1) Spring Tool (x1)
8
16
Now grab the jump mat and enclosure. Check where they attach
together and make sure each V-ring on the mat is threaded through the
corresponding hole on the net. Lay the mat with enclosure on the ground
inside the frame, and make sure the two warning labels are on top of the
mat and aligned with two T-joints!
STEP 5
Enclosure
Net (x1)
7
Jump Mat (x1)
5
(16)
To Next Page
