DISPLAY
·In Display setting menu, customer can set the topbar OSD time, turn off the time off, the OSD always on.
·In Display menu, customer can set the RSSI icon: icon + percentage, Icon, Percentage, disable, also
adjust the vertical position of the RSSI.
··The Luminance of the screen and be adjust in the menu (3 stages, default is 2).Normally do not set the
brightness too high unless the image is dim.
·In Display setting menu, customer can change the aspect ratio(4:3 or 16:9), default is 16:9.
·System Language can select in to: English, rench, erman, ussian, talian, ortuguese, panish,F G R I P S
Chinese, Japanese, Korean.
RF MODE：in this mode, user can chosse the Diversity mode or MIX mode, there are some cameras
video signal voltage didnt follow standard NTSC or PAL, which caused the picture rolling in MIX
mode,Select Diversity mode, it will solve the rolling issue.
·The built-in fan can not only be mainly used for defogging, but also can be used to dissipate the heat
within the product. The speed of fan can be set in the system menu.
·Press the POWER button to start up/stop the fan for defogging.
·User can manually set fan speed to adjust the fan noise.
·In Power supply menu, user can choose battery type(2S~6S) to make sure goggles shown real capacity
of the battery.
·Voltage calibration gives user ±0.9V range to adjust the voltage, when calibrate the voltage, use
multimeter to measure the loaded voltage of the battery, then use shuttle wheel to adjust voltage on OSD
to match the real voltage.
·RSSI Calibration: use can calibrate the rssi in this menu, to calibrate the RSSI, user need remove the
antenna, and turn off the VTX, then select yes, when calibration is done, the goggle will beep.
·Factory Reset : User can reset all the function and setting in this menu.
·DVR FW upgrade:User can upgrade DVR Firmware from SD card in this menu.
·Firmware version :Goggles Firmware , DVR Firmware version and Serial Number will shown in this menu.
The function of the wheel and buttons can be swapped from left side to the right side , makes to adapt
left handed user. when rotary switch is enabled, all the function in manual is changed from left to right.
SYSTEM MENU
6
