Quick Start Guide
1.Install the antenna and faceplate.
2.Use power cables to connect battery to the goggles, goggles can power by 2~6cell lipo battery, hold
the power button to turn on.
3.Focus adjustment: move the focus adjustment wheel to focus, close one eye to adjust the focus, you can
pop up the OSD menu as the template, when the image is clear, repeat the process with the other eye.
4.IPD adjustment: move the IPD slider until there is no double vision of the image.
Band /Channel / Receiver mode setting
1. Press the right wheel, then roll right wheel to change channel, press the wheel again switch to Band
setting mode, then roll the wheel to change the Band. Press wheel again to select diversity or Mix mode .
2.No wheel operation for 3 seconds，RF setting will quit the channel setting mode.
3. Hold the right wheel to pop up search menu, press the right wheel to start auto search, after searching
all the frequency, receiver will work on the strongest signal. Roll the right wheel to manually select the
channels, hold the right wheel to quit searching.
Sometime the auto search channel is not accurate, user may need manually select the channel.
Volume Setting
·In all mode preview mode, roll the left wheel to adjust the volume.
·Volume setting is only effective on earbud. Not effective on AV OUT volume.
·System didn't save the volume setting, in case of the volume is too high in AVIN or RF mode.
DO NOT EXPOSE THE LENS DIRECT TO SUNLIGHT, OTHERWISE
THE SCREEN WILL BURN IN.
Receiver Mode
MIX1: Mix1 mode provides basic fusion processing to reduce excessive intervention of the circuit on
the picture
MIX2: Mix2 mode improves synchronization stability, especially under weak signal to maximize
synchronization and lock video
MIX3: Mix3 mode enhances the synchronization signal on the basis of Mix2, maximizes the stability
of the video image, and maximizes compatibility with other display devices. In this mode, the
brightness of the video signal will be reduced
DIV: Div mode, the fusion processing will be turned off, and the receiver will work in the traditional
diversity receiving mode, and the audio and video signal output corresponding to the channel
with the highest RSSI intensity will be selected.
Drone Finder Mode
Install a patch antenna on RX, long press the left wheel to enable drone finder function(long press
again to disable), the buzzer frequency will synchronize with RSSI, the strongger the RSSI is, the
rapider of sound the buzzer.
