6
SYSTEM MENU
·Power supply menu, user can choose battery type(2S~6S) to make sure goggles show real capacity
of the battery
·Voltage calibration gives user ±0.9V range to adjust the voltage, when calibrate the voltage, use
multimeter to measure the loaded voltage of the battery, then use shuttle wheel to adjust voltage.
·RSSI Calibration: use can calibrate the RSSI in this menu, to calibrate the RSSI, user need remove the
antenna, and turn off the VTX, then select yes, when calibration is done, the goggle will beep.
·System Language can select in to: English, rench, erman, ussian, talian, ortuguese, panish, F G R I P S
Chinese, Japanese, Korean.
·T he built-in fan can not only be mainly used for defogging, but also can be used to dissipate the heat
. the speed of fan can be set in the system menu, press the POWER button to start up/stop the fan.
.
I
·Factory Reset : User can reset all the functions and settings in this menu.
·DVR FW upgrade:User can upgrade DVR Firmware from SD card in this menu.
·Firmware version :Goggles Firmware , DVR Firmware version and Serial Number will show in this menu.
The function of the wheel and buttons can be swapped from left side to the right side , make to adapt
left handed user. when rotary switch is enabled, all the functions in manual are changed from left to right.
Display
· In Display setting menu, customer can set the topbar OSD time, disable OSD time out, the OSD always on.
·I n Display menu, customer can set the RSSI icon: Icon + percentage, Icon, Percentage, Disable, also
adjust the vertical position of the RSSI.
·The Luminance of the LCOS screen and be adjust in the menu (8 stage, default is 5).Normally do not
set the brightness too high unless the image is dim.
· Sleep MODE: To prevent screen burn out, the goggles have sleep mode, The sleep mode can be set
in the menu( 1minute 3minutes 5 minutes, default 3 minutes.) When sleep mode is enabled the goggles
will detect the movement of the goggles (via headtracker gyro), when the goggles stay still to the preset
time , the buzzer will beep , after 10 seconds, the goggles will switch to sleep mode , the screen will turn
off, move the goggles to quit sleep mode.
· In Display setting menu, customer can change the aspect ratio(4:3 or 16:9), default is 4:3. also user
can switch to small fov mode, image will cut at the edge on screen.
· When sleep mode is triggered, the rest functions of goggle is still working (receiver ,DVR etc).
To quit Sleep mode: Move the goggles when hearing beep.
·
<Auto&Follow> on, the DVR will auto start recording when video signal is on, and stop recording after 30s
when signal is cut, if signal is on again, DVR will start recording again.
<Follow> Press the REC button to manully start recording，DVR will stop recording after 30s when signal
is cut, but it will auto start recording when signal is on. press REC button agian can manully stop rec to
save SD card space.
Cyclic recording：Overwriting of older recordings on or off (in case of storage space is wasted).·
·The video recording File will be automatically divided into the multiple Files. In the menu system, the
video length can be set as: 5 minutes, 10 minutes, 20 minutes and 30 minutes. The default video length
can be set as 30 minutes / each File. If the power has been suddenly disconnected in the video recording·
process, the DVR will be damaged.
The goggles have repairing function. After entering into the Playback mode, the last DVR file will be
automatically checked. If it has been damaged, the DVR file will be automatically repaired.
