IF302 - Operation and Maintenance Instruction Manual
4.4
Spare Parts List
SPARE PARTS LIST
DESCRIPTION OF PARTS POSITION CODE
CATEGORY
(NOTE 4)
Cover Without Window (Includes O-Ring)
Aluminium 1 and 15 204-0102
316 Stainless Steel 1 and 15 204-0105
Cover With Window for Indication (Includes O-Ring)
Aluminium 1 204-0103
316 Stainless Steel 1 204-0106
O-Rings (Note 2) Cover, Buna-N 2 204-0122 B
Aluminium Housing Main Board Screw
Units With Indicator 3 304-0118
Units Without Indicator 3 304-0117
316 Stainless Steel Housing Main Board Screw
Units With Indicator 3 204-0118
Units Without Indicator 3 204-0117
Digital Indicator 4 214-0108
Main and Input Circuit Board Assembly 5 and 7 334-0150 A
Input Board Screw
Aluminium Housing 6 314-0125
316 Stainless Steel Housing 6 214-0125
Cover Locking Screw 8 204-0120
Housing, Aluminium (Note 1)
½ - 14 NPT 9 324-0150
M20 x 1.5 9 324-0151
PG 13.5 DIN 9 324-0152
Housing, 316 Stainless Steel (Note 1)
½ - 14 NPT 9 324-0153
M20 x 1.5 9 324-0154
PG 13.5 DIN 9 324-0155
Local Adjustment Protection Cap 10 204-0114
Identification Plate Fixing Screw 11 204-0116
Terminal Insulator 12 314-0123
External Ground Screw 13 204-0124
Terminal Holding Screw
Housing in Aluminium 14 304-0119
Housing in 316 Stainless Steel 14 204-0119
Six-Sided Plug 1/2" NPT Internal BR Ex
Bichromated Carbon Steel 16 400-0808
Bichromated 304 Stainless Steel 16 400-0809
Six-Sided Plug 1/2" NPT Internal
Bichromated Carbon Steel 16 400-0583-11
Bichromated 304 Stainless Steel 16 400-0583-12
Six-Sided Plug M20 X 1.5 External BR Ex d 316 Stainless Steel 16 400-0810
Six-Sided Plug PG13.5 External BR Ex d 316 Stainless Steel 16 400-0811
Mounting Bracket for 2” Pipe Mounting (Note 3)
Carbon Steel - 214-0801
316 Stainless Steel - 214-0802
Carbon Steel Bolts, Nuts, Washers
and U-clamp in Stainless Steel
- 214-0803
Note: 1 - It includes terminal holder insulator, bolts (cover lock, grounding and terminal holder insulator) and identification plate without
certification.
2 - 0-Rings are packaged in packs of 12 units.
3 - Including U-clamp, nuts, bolts and washers. Spare Parts List
4 - For category A, it is recommended to keep, in stock, 25 parts installed for each set, and for category B, 50.
