Installation Manual STR7202 TAG4 & SFM7704 TAG1
DBCI-0512-0052-V013
STR7202 2-Side Trimmer & SFM7704 Square Fold Module
Name: RI01
Date: 29-3-2017
Page: 69 / 72
8. Technical Information
Contents
8.1 STR7202 2-Side Trimmer
Capabilities:
Compatibility:
Canon Booklet Trimmer D1 & F1
Physical:
Operational
On Pallet in box
Height
1300 mm 1570 mm
Width
700 mm
800 mm
Depth
600 mm
1200 mm
Weight
~ 216 Kg
~ 283 Kg
Booklet
Before trimming:
Bypass:
Trimmed:
Minimum booklet height (Z):
204 mm
150 mm
200 mm
Maximum booklet height (Z):
340 mm
320 mm
320 mm
Note:
Booklet heights between 320 mm and 340 mm must be trimmed back
to 320 mm or less.
Minimum booklet width (X):
50 mm
Maximum booklet width (X):
245 mm
Maximum Booklet Thickness:
5 mm
Trimming size (min-max)
2 mm 35 mm each side
A-symmetrical trim (min-max)
±15 mm
Booklet Staple Clearance from
top/bottom (minimal)
40 mm
Paper Weight (min-max)
60 g/m
2
- 300 g/m
2
Note:
O
n booklets from about 20 sheets or more, always use coversheets
from 120 g/m
2
or higher to prevent possible deviations (like crinkles) on
the booklet.
Technical:
Speed
1800 booklets/hour
Noise Level (max)
70 dB
