Smart Dedicated Design STR7202 - Basic Information

Installation Manual STR7202 TAG4 & SFM7704 TAG1
DBCI-0512-0052-V013
STR7202 2-Side Trimmer & SFM7704 Square Fold Module
Name: RI01
Date: 29-3-2017
Page: 8 / 72
3. Basic information
Contents
Study the picture below to become familiar with the main components.
NOTE:
Orientation is based on the paper flow direction.
No.
Description
1.
Top Cover STR
2.
Trim Waste Bin
3.
Operator Side (Left)
4.
User Interface (UI)
5.
Power switch (inside)
6.
Top Cover SFM7704
7.
Square Fold Module SFM7704 (Option)
8.
Belt Stacker
Front
Rear
Left
Right
Top
2
5
Bottom
8
1
3
4
6
7
