8 Technical Information (continued)
Contents
8.2 SFM7704 Square Fold Module
Capabilities:
Compatibility:
Online:
STR7202
Physical:
Operational
On Pallet in box
Height
1300mm
720mm
Width
600mm
800mm
Length
360 mm
1200mm
Weight
~ 65 Kg
~ 100Kg
Booklet:
Width
Length
Min. - Max. paper size:
from 2-Side Trimmer
Paper Weight (min-max)
60 g/m
2
- 300 g/m
2
Technical:
Speed
A4
A3
1800 booklets/hour
1800 booklets/hour
Noise Level (max)
70dB
Electrical:
Power source:
from 2 Side Trimmer
Environmental:
Temperature Range
+17 to 32°C
Humidity Range
30% – 65% RH
