Check the water valve in the bathroom. You may need to consider purchasing additional components.
For the following case, the T-valve alone is sufficient for connection.
Once the base plate is attached to the unit, align
the unit and toilet fixture facing front, and then
insert the mounting bolts
to the toilet mounting holes.
Put the bolt into the bolt case and align it with the
top of the base plate. Insert bolt with bolt case onto
the base plate. After this is done hold the bolts,
slide it into the bottom of the unit until it snaps in
place.
Install the main unit and insert the mounting
bolts to the toilet mounting holes.
Connect the flexible tube from side of T-valve
to the unit. Turn the water valve to the left to
allow water to flow.
Installed bolt case
Bolt
Bolt
Back
Base plate
Cone Packing
Nut
Water supply valve
※ Customers should use the new hose set provided with the product.
Do not use used set again.
Water supply hose for
electronic toilet seat
11
Cone Packing
Nut
E
N
G
L
I
S
H
