ACC4100 Diesel Air Compressor Controller User Manual Page 21 of 52
No.
Item
Range
Default
Description
7
Warming Up Time
(0-3600)s
0
Warming up time for engine before normal
running after high speed running.
8
Cooling Time
(0-3600)s
0
Cooling time before stop
9
Stop Idle Time
(0-3600)s
10
Time for engine idle running in stop
process.
10
ETS Solenoid Hold
(0-3600)s
20
Time for ETS to be energized before stop.
11
Wait Stop Time
(0-3600)s
0
Time after idle running delay before
complete stop when ETS Solenoid Hold is
set 0; When it is not 0, it is time after ETS
delay before complete stop.
12
After Stop Time
(0-3600)s
0
Time from complete stop to standby
status.
13
Fuel Pre-supply Rest
Time
(0-12)h
2
Interval time from this pre-supply is
completed to next pre-supply is outputted
when output is configured to fuel
pre-supply in standby state; when it is set
to 0, pre-supply will not output in standby
state.
14
Fuel Pre-supply Time
(3-30)s
5
Time for pre-supply output when output is
configured to fuel pre-supply.
Engine Setting
1
Engine Type
(0-39)
34
Default: 34: GTSC1;
2
Enable ECU Alarm Shut
(0-1)
1
0: Disable 1: Enable
NOTE: When engine detects red light alarm, it will
stop when it is enabled;
3
Source of Speed Signal
(0-1)
0
0: Speed Sensor 1: W/L
4
W/L Ratio
(0-99.99)
9.04
5
Flywheel Teeth
(1.0-300.0)
118.0
Flywheel teeth of engine, used for starter
disconnect conditions and engine speed
detection; please refer to the below
installation.
6
Rated Speed
(0-6000)r/min
2200
Provide standard for over speed, under
speed and load speed detection.
7
Start Attempts
(1-10)times
3
Maximum start times in case of failed
start; when this number is reached,
controller shall issue Failed to Start signal.
8
Crank Disconnect
(0-2)
2
Please refer to Table 12;
There are two kinds of disconnect
conditions for engine and starter. They can
be used independently or together and the
purpose is to separate starter motor and
engine as soon as possible.
9
Disconnect Speed
(0-200)%
24
Set value is the percentage of rated speed;
when speed is above the set value, starter
