Smartgen ACC4100 User Manual

ACC4100 Diesel Air Compressor Controller User Manual Page 25 of 52
No.
Item
Range
Default
Description
set.
6
Over Warn
(0-30000)kPa
2000
When external sensor value is larger than
this value, controller issues warning alarm;
alarm enable, return and delay values can
be set.
7
Under Warn
(0-30000)kPa
200
When external sensor value is less than
this value, controller issues warning alarm;
alarm enable, return and delay values can
be set.
8
Custom Curve
When custom resistance/current/voltage
types are selected; related curve needs to
be set.
Flexible Sensor 1~4 Setting
1
Sensor Type
(0-3)
0
0: Not Used
1: Engine Temperature Sensor
2: Engine Oil Pressure Sensor
3: Temperature Sensor
4: Oil Pressure Sensor
5: Level Sensor
2
Curve Type
Changes according to sensor types;
3
Open Action
(0-2)
0
0: Warning 1: Shutdown 2: None
4
Display Unit
(0-1)
0
0: °C 1: °F
NOTE: Unit is different for different sensor.
5
Over Shutdown
(0-9000)
100
When external sensor value is larger than
this value, controller issues shutdown
alarm; Alarm enable and delay value can
be set.
6
Under Shutdown
(0-9000)
10
When external sensor value is less than
this value, controller issues shutdown
alarm; alarm enable and delay value can be
set.
7
Over Warn
(0-9000)
90
When external sensor value is larger than
this value, controller issues warning alarm;
alarm enable, return and delay values can
be set.
8
Under Warn
(0-9000)
20
When external sensor value is less than
this value, controller issues warning alarm;
alarm enable, return and delay values can
be set.
9
Custom Curve
When custom resistance/current/voltage
types are selected; related curve needs to
be set.
Engine Temperature Related Setting
1
Sensor Correlate Set
(0-4)
0
0: Not Used
1: Flexible Sensor 1
