ACC4100 Diesel Air Compressor Controller User Manual Page 26 of 52
No.
Item
Range
Default
Description
2: Flexible Sensor 2
3: Flexible Sensor 3
4: Flexible Sensor 4
2
Heater Control
((-50)-300)°C
50
When the external temp. sensor value is
less than this value, heater control outputs;
Return and delay value can be set.
3
Cooler Control
((-50)-300)°C
80
When the external temp. sensor value is
higher than this value, cooler control
outputs; Return and delay value can be set.
Engine Oil Pressure Related Setting
1
Sensor Correlate Set
(0-4)
0
0: Not Used
1: Flexible Sensor 1
2: Flexible Sensor 2
3: Flexible Sensor 3
4: Flexible Sensor 4
Discharge Temp. Display Related Setting
1
Sensor Correlate Set
(0-4)
0
0: Not Used
1: Flexible Sensor 1
2: Flexible Sensor 2
3: Flexible Sensor 3
4: Flexible Sensor 4
Digital Input Ports
Digital Input 1
1
Contents Setting
(0-53)
3
Alarm Reset;
Please refer to Table 11 for details.
2
Active Type
(0-1)
0
0: Close 1: Open
Digital Input 2
1
Contents Setting
(0-53)
26
High Temp. Shutdown Input;
Please refer to Table 11 for details.
2
Active Type
(0-1)
0
0: Close 1: Open
Digital Input 3
1
Contents Setting
(0-53)
27
Low Oil Pressure Shutdown Input;
Please refer to Table 11 for details.
2
Active Type
(0-1)
0
0: Close 1: Open
Digital Input 4
1
Contents Setting
(0-53)
0
Users defined;
Please refer to Table 11 for details.
2
Active Type
(0-1)
0
0: Close 1: Open
3
Active Range
(0-3)
2
0: From Safety On
1: From Crank
2: Always
3: Never
4
Active Action
(0-2)
0
0: Warning 1: Shutdown 2: Indication
5
Active Delay
(0-20.0)s
2.0
Time from detecting input is active to
