ACC4100 Diesel Air Compressor Controller User Manual Page 27 of 52
No.
Item
Range
Default
Description
confirm;
6
Input Description
Users defined;
Digital Input 5
1
Contents Setting
(0-53)
0
Users defined;
Please refer to Table 11 for details.
2
Active Type
(0-1)
0
0: Close 1: Open
3
Active Range
(0-3)
2
0: From Safety On
1: From Crank
2: Always
3: Never
4
Active Action
(0-2)
0
0: Warning 1: Shutdown 2: Indication
5
Active Delay
(0-20.0)s
2.0
Time from detecting input is active to
confirm;
6
Input Description
Users defined;
Auxiliary Outputs
Auxiliary Output 1
1
Contents Setting
(0-129)
29
Fuel relay output;
Please refer to Table 10 for details.
2
Output Type
(0-1)
0
0: Normally Open
1: Normally Close
Auxiliary Output 2
1
Contents Setting
(0-129)
28
Starting relay output;
Please refer to Table 10 for details.
2
Output Type
(0-1)
0
0: Normally Open
1: Normally Close
Auxiliary Output 3
1
Contents Setting
(0-129)
30
Idle speed control;
Please refer to Table 10 for details.
2
Output Type
(0-1)
0
0: Normally Open
1: Normally Close
Auxiliary Output 4
1
Contents Setting
(0-129)
26
Load control;
Please refer to Table 10 for details.
2
Output Type
(0-1)
0
0: Normally Open
1: Normally Close
Auxiliary Output 5
1
Contents Setting
(0-129)
39
Normal running output;
Please refer to Table 10 for details.
2
Output Type
(0-1)
0
0: Normally Open
1: Normally Close
Auxiliary Output 6
1
Contents Setting
(0-129)
42
Common alarm;
Please refer to Table 10 for details.
2
Output Type
(0-1)
0
0: Normally Open
