Smartgen APC715 User Manual

APC715 Pump Unit Controller
APC715 Pump Unit Controller ISSUE 2013-08-28 Version 1.0 Page 35 of 62
No.
Items
Parameter
Default
Description
1
Contents
Setting
(0-53)
0
User defined. See form 3.
2
Active Type
(0-1)
0
0: Closed to active 1: Open to
active
3
Arming
(0-3)
0
0: From safety on 1: From starting
2: Always 3:Never
4
Active
Actions
(0-4)
0
0: Warn; 1: Shutdown; 2: Trip
Shutdown 3: Fault Idle 4: Indication
5
Active Delay
(0-20.0)s
2.0
Time from detecting active to
confirm.
6
Description
User defined.
Flexible Output Ports
Flexible Output Port 1
1
Contents
Setting
(0-239)
1
User defined period output (default
output is in preheating) See form 4.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally
close
Flexible Output Port 2
1
Contents
Setting
(0-239)
35
Idle speed control. See form 4.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Flexible Output Port 3
1
Contents
Setting
(0-239)
29
On-load control. See form 4.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Flexible Output Port 4
1
Contents
Setting
(0-239)
31
Reserved. See form 4.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Flexible Output Port 5
1
Contents
Setting
(0-239)
38
ETS solenoid hold. See form 4.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Flexible Output Port 6
1
Contents
Setting
(0-239)
48
Common alarm. See form 4.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Flexible Output Port 7~10
1
Contents
Setting
(0-239)
0
Not used. See form 4.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
GOV Setting
