HGM400N Series Genset Controller User Manual Page 5 of 38

generator, controller has over voltage, under voltage, over frequency, under frequency, over current

and over power detection functions;

 Precisely collect and display all parameters of engine:

Temp. (WT) °C/°F

Oil pressure (OP) kPa/psi/bar

Fuel Level (FL) % Residual Fuel Level L

Engine Speed (RPM) r/min

Battery Voltage (VB) V

Charger Voltage (VD) V

Hours Counter (HC)

Start times

 Control and protection function: automatic start/stop of the genset, ATS (Auto Transfer Switch)

control and perfect fault indication and protection function;

 ETS (Energize to stop), idle control, pre-heat control, speed raise control and speed drop control

functions, and all output ports are relay outputs;

 Parameter setting function: allows users to modify and set the parameters and meanwhile will be

stored in internal FLASH and won't be lost even in case of power outage; all controller parameters

can be adjusted on front panel of the controller or via USB interface on PC;

 Multiplex input port 3 and 4 can be used in various occasions: input 3 can be used as auxiliary input

port or fuel level sensor, while input 4 can be used as auxiliary input port or configurable sensor;

 Multiple temperature, oil pressure, and fuel level sensors can be used directly, and parameters can

be user-defined;

 One configurable sensor: can be set to temperature sensor, oil pressure sensor or fuel level sensor,

which enables the detection of double temperatures, double oil-pressures and double fuel levels.

 Multiple crank disconnect conditions (magnetic pickup, oil pressure, generator) are optional;

 Emergency start function;

 Flywheel teeth auto-recognition function;

 Wide power supply range: DC(8~35)V, which suitable for different starting battery voltage

environments;

 All parameters apply digital adjustment, instead of conventional analog modulation with normal

potentiometer, improving the wholesome reliability and stability;

 Maintenance function: types can be set to date or running time. Actions (inactive, warning, alarm

shutdown) can also be set when maintenance time is out;

 Event log function (max. 99 pieces of records), real-time clock, and schedule to start/stop generator

function (start once monthly/weekly/daily on/off load can be set);

 IP55 waterproofness with rubber-ring gasket between enclosure and screen;

 Metal fixing clips are used to fix the controller;

 Modular design, self-extinguished ABS plastic enclosure, pluggable connection terminals and

embedded installation way; compact structure with easy mounting.
