HGM6100N Series Genset Controller User Manual Page 18 of 47
No.
Function
Cable Size
Description
31
Mains R phase Voltage
Sensing Input
1.0mm
2
Connect to mains R phase (2A fuse is recommended)
HGM6110 without
32
Mains S phase Voltage
Sensing Input
1.0mm
2
Connect to mains S phase (2A fuse is recommended)
HGM6110 without.
33
Mains T phase Voltage
Sensing Input
1.0mm
2
Connect to mains T phase, (2A fuse is recommended)
HGM6110 without.
34
Mains N1 Input
1.0mm
2
Connect to mains N-wire, HGM6110 without.
35
RS485 Common Ground
/
Impedance-120Ω shielding wire is recommended, its
single-end connect with ground.
36
RS485-
0.5mm
2
37
RS485+
0.5mm
2
38
Aux. Input 4
1.0mm
2
Ground connected is active (B-).
Reference Table 9
39
Aux. Input 5
1.0mm
2
Ground connected is active (B-).
40
Sensor Common
1.0mm
2
Sensor common port.
41
CAN COM
0.5mm
2
Impedance-120Ω shielding wire is recommended, its
single-end connect with ground (the controller without
CANBUS function doesnt have this terminal).
42
CAN L
0.5mm
2
43
CAN H
0.5mm
2
44
NULL
NOTE: USB ports in controller rear panel are programmable parameter ports; user can directly program via PC.
