HGM6100N Series Genset Controller User Manual Page 7 of 47

Each and total active power kW

Reactive power kvar

Apparent power kVA

Power factor PF

Generator accumulated energy kWh

Output percentage with load %

 For mains, genset has functions of over/under voltage and loss of phase; For gens, genset has

functions of over/under voltage, over/under frequency, over current and over power;

 Precision measure and display of parameters about engine;

Temp. (WT) °C/°F

Oil pressure (OP) kPa/psi/bar

Fuel level (FL) % Fuel remains L

Speed (SPD) r/min

Battery Voltage (VB) V

Charger Voltage (VD) V

Accumulated running hours

Accumulated start times

 Control and protection function: Automatic start/stop of genset, load transfer (ATS control) and

perfect fault display and protection;

 With ETS, idle control, pre-heat control, speed raise/drop control, all of them are relay outputs;

 Parameter setting: Allow user to modify setting and store them in internal FLASH memory. The

parameters cannot be lost even when power off. All of parameters can be set not only from the front

panel, but also adjusted through USB interface (or RS485 interface) via PC;

 Multiple sensors of temperature, pressure and fuel level can be used directly, parameters can be

defined by user;

 Multiple conditions of crank disconnect (speed, oil pressure, frequency) can be selected;

 With emergency start function;

 With flywheel teeth numbers automatic identification function;

 Power supply range: (8~35)VDC, accommodating to different starting battery voltage environment;

 All parameters use digital modulation, instead of analog modulation using conventional

potentiometer, having improved reliability and stability;

 With maintenance function. Types (date or running time) can be selected and actions (warning or

alarm shutdown) can be set when maintenance time out;

 Event log, real-time clock, scheduled start & stop function (can be set as start unit once a

day/week/month whether with load or not);

 Add rubber gasket between shell and controller screen, the waterproof can reach IP65;

 Controller is fixed by metal fixing clips;

 Modular design, flame-retardant ABS shell, pluggable terminal, embedded mounting, compact

structure and easy installation.
