8 GB/IE
Parts Description
Before reading, unfold the page containing the illustrations and famil-
iarise yourself with all functions of the device.
1
Camera
2
Mounting bracket
3
WLAN aerial
4
Tutorial CD
5
Wall plug
6
Screws
7
Power supply
8
Ethernet cable (see Fig. B)
9
RJ-45 connection element
10
RESET button (see Fig. B)
11
SD slot (for micro SD card max. 32 GB Class 10 - not included)
(see Fig. B)
12
Quick start guide with instructions for assembly and use, and
safety notices
13
Decal for marking the area under surveillance
Technical Data
Camera:
Device type: Surveillance Camera WLAN Outdoor
IP66
Dimensions: approx. 6 x 11 cm (ø x d), approx.
6 x 15.5 cm (ø x d) (with WLAN aerial
and sun screen)
Image sensor: 2 megapixel CMOS
Focal length: 3.6mm
